Status and Statistics
System Summary
48 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
5
• Firmware Version (Non-active)—Firmware version number of the non-active image.
If the system is in a stack, the version of the master unit is displayed.
• Firmware MD5 Checksum (Non-active)—MD5 checksum of the non-active image.
NOTE The following three fields can appear twice - once for each language on the
device.
• Locale—Locale of the first language. (This is always English.)
• Language Version—Language package version of the first or English language.
• Language MD5 Checksum—MD5 checksum of the language file.
TCP/UDP Services Status:
To reset the following fields, click Edit to open the TCP/UDP Services page.
• HTTP Service—Whether HTTP is enabled/disabled.
• HTTPS Service—Whether HTTPS is enabled/disabled.
• SNMP Service—Whether SNMP is enabled/disabled.
• Telnet Service—Whether Telnet is enabled/disabled.
• SSH Service—Whether SSH is enabled/disabled.
PoE Power Information on Master Unit: (on devices supporting PoE)
• PoE Power Information on Master Unit—Click on Detail to link you directly to the
PoE Properties page. This page shows the PoE power information on a per-unit basis.
• Maximum Available PoE Power (W)—Maximum available power that can be
delivered by the switch.
• Total PoE Power Consumption (W)—Total PoE power delivered to connected PoE
devices.
• PoE Power Mode—Port Limit or Class Limit.
The master unit is displayed graphically, as shown below:
Hovering on a port displays its name.
