SNMP
Notification Recipients
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 465
24
• Recipient IP Address/Name—Enter the IP address or server name of where the traps
are sent.
• UDP Port—Enter the UDP port used to for notifications on the recipient device.
• Notification Type—Select whether to send traps or informs. If both are required, two
recipients must be created.
• Timeout—Enter the amount of time (seconds) the device waits before re-sending
informs/traps. Timeout: Range 1-300, default 15
• Retries—Enter the number of times that the device resends an inform request. Retries:
Range 1-255, default 3
• User Name—Select from the drop-down list the user to whom SNMP notifications are
sent. In order to receive notifications, this user must be defined on the Users page, and
its engine ID must be remote.
• Security Level—Select how much authentication is applied to the packet.
NOTE The Security Level here depends on which User Name was selected. If this User
Name was configured as No Authentication, the Security Level is No Authentication
only. However, if this User Name has assigned Authentication and Privacy on the Users
page, the security level on this screen can be either No Authentication, or
Authentication Only, or Authentication and Privacy.
The options are:
- No Authentication—Indicates the packet is neither authenticated nor encrypted.
- Authentication—Indicates the packet is authenticated but not encrypted.
- Privacy—Indicates the packet is both authenticated and encrypted.
• Notification Filter—Select to enable filtering the type of SNMP notifications sent to
the management station. The filters are created in the Notification Filter page.
• Filter Name—Select the SNMP filter that defines the information contained in traps
(defined in the Notification Filter page).
STEP 4 Click Apply. The SNMP Notification Recipient settings are written to the Running
Configuration file.
