Smart Network Application (SNA)
Right-Hand Information Panel
484 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
25
The following information is displayed for offline backbone devices under Last Known
Information:
The following information is displayed for a client (end point device, such as a PC):
Parameter Name Notes Example
Product Name Taken from the device description
MIB.
This field only appears when the
device is a switch with partial or full
SNA capabilities.
SG500-52P - 52-Port Gigabit
PoE Stackable Managed
Switch
Host Name String of up to 58 characters RND_1
IP Address Displays the last IP address used to
connect to the device when last seen.
192.168.1.55
MAC Address The base MAC address of the device 00:00:b0:83:1f:ac
Description Editable field of a maximum of 80
characters.
Last seen The date and time the device was last
seen by SNA in the format of the active
language file.
English language file
example:
2015-Nov-04 17:17:53
Parameter Name Notes Example
Host Name String of a maximum of 58 characters RND_1
IP Address Shows the IP address used by SNA to
connect to the device. Additional
advertised addresses (IPv4 and IPv6)
can be seen by clicking an icon next to
the label.
192.168.1.55
923:a8bc::234
MAC Address The base MAC address of the device 00:00:b0:83:1f:ac
Device Type The type of client device Phone
Host
Unknown
Connected
Interface
The interface through which the
device is reached on the closest switch
GE1/14
