Smart Network Application (SNA)
Search
504 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
25
The search term entered is searched in the information known to SNA.
The following items can be searched:
IP addresses
MAC addresses
Host name
Product Name
Description
Tags
The search results are displayed as a list of clickable identification cards. If an identification
card is clicked, the topology map becomes centered and zooms on its topology element.
The search can be refined by adding keywords to limit the fields searched. If you enter a
keyword followed by a colon and the search term, the search term is searched for only in the
specified field. The following are the supported keywords: IP, MAC and Tag.
If the search term is contained in quotes, only exact matches are found.
The following is an example of searching by tag:
STEP 1 Click in the Search box:
STEP 2 Enter the keyword “Tag” and the name of the tag, as shown in the example below:
STEP 3 Click . The results are displayed.
