Step 3 Remove the dust cover from the port end of the transceiver.
Step 4 Insert the transceiver into the port:
• If the transceiver has a Mylar tab, position the transceiver with the tab on the bottom, and then gently
insert the transceiver into the port until it clicks into place.
• If the transceiver has a bale clasp, position the transceiver with the clasp on the bottom, close the clasp
by pushing it up over the transceiver, and then gently insert the transceiver into the port until it clicks
into place.
• If the transceiver does not install easily, ensure that it is correctly positioned and the tab or clasp are in
the correct position before continuing.
If you cannot install the cable into the transceiver, insert or leave the dust plug in the cable end of
the transceiver.
Note
Removing a Transceiver
Use an SFP28 transceiver to connect to an Ethernet or Fibre Channel port.
Excessively installing and removing an SFP or SFP28 transceiver can shorten its life. Do not remove and
install transceivers unless it is absolutely necessary. We recommend disconnecting cables before installing
or removing transceivers to prevent damage to the cable or transceiver.
Caution
Procedure
Step 1 Attach an ESD wrist strap and follow the instructions for its use.
Step 2 If a cable is installed in the transceiver:
a) Record the cable and port connections for later reference.
b) Press the release latch on the cable, grasp the connector near the connection point, and gently pull the
connector from the transceiver.
c) Insert a dust plug into the cable end of the transceiver.
If the transceiver does not remove easily in the next step, push the transceiver completely in and then
ensure that the latch is in the correct position before continuing.
Step 3 Remove the transceiver from the port:
• If the transceiver has a Mylar tab latch, gently pull the tab straight out (do not twist), and then pull the
transceiver out of the port.
• If the transceiver has a bale clasp latch, open the clasp by pressing it downwards, and then pull the
transceiver out of the port.
If you cannot remove the SFP28 transceiver, reseat it by returning the bale clasp to the up
position. Press the SFP28 transceiver inward and upward into the cage. Next, lower the bale
clasp and pull the SFP28 transceiver straight out with a slight upward lifting force. Be careful
not to damage the port cage during this process.
Note
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
34
Connecting the Cisco UCS Fabric Interconnect
Removing a Transceiver

Cisco UCS 6454 Specifications

General

Product Type	Fabric Interconnect
Ports	54
USB Ports	1 x USB 2.0
Form Factor	1 RU
Management	Cisco UCS Manager
Port Types	FCoE, FC
Downlink Ports	48 x 10/25 Gbps SFP28
Management Ports	1 x 1 Gbps RJ45
Console Ports	1 x RJ45
Latency	Less than 1 microsecond
Redundancy	Redundant power supplies and fans
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5 to 95% relative humidity, noncondensing
Power Supply	650W AC, hot-swappable
