DescriptionLED State
Major fan alarm (two or more fans are missing or have failed, or there is a fan direction
mismatch
Solid red
Port LEDs
The port LED states are listed below.
DescriptionLED State
Enabled, but SFP not inserted
Administrative down (software shutdown)
Yellow
Enabled and link is upGreen
Enabled, but link is not connectedOff
Power On Self Test (POST) failed
Port beacon enabled
Blinking yellow
L1 and L2 Port LEDs
The L1 and L2 port LED states are listed below.
DescriptionLED StateLED Position
No linkOffLeft
Physical linkSolid greenLeft
No activityOffRight
ActivityBlinking greenRight
Supported Transceivers
The Cisco UCS 6454 Fabric Interconnect support SFP28 Ethernet transceivers, SFP transceivers, SFP28
transceivers, SFP28 copper twinax cables with integrated transceivers, SFP Fibre Channel transceivers, QSFP
transceivers, QSFP28 transceivers, and QSFP cables. Except where noted, both the Cisco UCS 6454 Fabric
Interconnect support all the transceivers listed in this section. Ports 1–8 operate as unified ports that are capable
of 10/25-Gbps fixed Ethernet, 10/25-Gbps FCoE, or 8-, 16-, or 32 Gbps Fibre Channel ports.
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
8
Product Overview
Port LEDs

Cisco UCS 6454 Specifications

General

Product Type	Fabric Interconnect
Ports	54
USB Ports	1 x USB 2.0
Form Factor	1 RU
Management	Cisco UCS Manager
Port Types	FCoE, FC
Downlink Ports	48 x 10/25 Gbps SFP28
Management Ports	1 x 1 Gbps RJ45
Console Ports	1 x RJ45
Latency	Less than 1 microsecond
Redundancy	Redundant power supplies and fans
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5 to 95% relative humidity, noncondensing
Power Supply	650W AC, hot-swappable
