You now have terminal access. Depending on the prompt, you may have all Cisco UCS Manager CLI commands
or a very abbreviated set of configuration commands.
Connecting the Management Port
To prevent an IP address conflict, do not connect the management port to the network until the initial
configuration is complete. For configuration instructions, see the Configuration Guide for the version of Cisco
UCS Manager that you are using. The configuration guides are available at this URL: http://www.cisco.com/
c/en/us/support/servers-unified-computing/ucs-manager/products-installation-and-configuration-guides-list.html
Caution
The Ethernet management connector port has an RJ-45 interface that will connect to a switch or router.
Procedure
Step 1 Connect the appropriate modular cable to the Ethernet management connector port:
• Use modular, RJ-45, straight-through UTP cables to connect the port to an Ethernet switch or hub.
• Use a cross-over cable to connect to a router interface.
Step 2 Connect the other end of the cable to the device.
Connecting to an SFP28 Ethernet or Fibre Channel Port
Installing or Removing Cables into SFP Transceivers
To prevent damage to the fiber-optic cables, do not place more tension on them than the rated limit and do
not bend to a radius of less than 1 inch if there is no tension in the cable, or 2 inches if there is tension in the
cable.
Caution
Installing a Transceiver
Use an SFP28 transceiver to connect to an Ethernet or Fibre Channel port.
Procedure
Step 1 Attach an ESD wrist strap and follow the instructions for its use.
Step 2 Remove the dust cover from the port cage.
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
33
Connecting the Cisco UCS Fabric Interconnect
Connecting the Management Port
