Cisco UCS 6454 User Manual

System Status LED7
The status of the beacon and system status LEDs are as follows:
DescriptionStateColorFunctionLocationLED
Chassis
selected
Solid OnBlueIndicate selected
chassis
Front and rearBeacon
LED
Chassis not
selected
Off
Normal
operation
Solid onGreenIndicate system
power/health at bootup
and run time
Front and rearSystem
Status LED
System
powered off
Off
System
fault
OnAmber
Power shut
down by
software
Solid onRed
Secure boot
validation
has failed
Blinking
Management Port LEDs
The status of the management ports is listed below.
DescriptionLED StateLED Position
No linkOffLeft
Physical linkSolid green
No activity
OffRight
ActivityBlinking green
System Environment LEDs
The system environment LED states are listed below.
DescriptionLED State
Minor fan alarm (a fan is missing or there is a failure)Solid amber
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
7
Product Overview
Management Port LEDs

Cisco UCS 6454 Specifications

General

Product Type	Fabric Interconnect
Ports	54
USB Ports	1 x USB 2.0
Form Factor	1 RU
Management	Cisco UCS Manager
Port Types	FCoE, FC
Downlink Ports	48 x 10/25 Gbps SFP28
Management Ports	1 x 1 Gbps RJ45
Console Ports	1 x RJ45
Latency	Less than 1 microsecond
Redundancy	Redundant power supplies and fans
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5 to 95% relative humidity, noncondensing
Power Supply	650W AC, hot-swappable
