Cisco UCS 6454 User Manual

DateTimeVerified ByPlanning ActivityTask No.
Cable and interface
equipment
evaluation:
• Cable type
• Connector type
• Cable distance
limitations
• Interface
equipment
(transceivers)
5
EMI evaluation:
• Distance
limitations for
signaling
• Site wiring
• RFI levels
6
4
Verify that the power supply installed in the chassis has a dedicated AC source circuit.
5
UPS = uninterruptible power supply.
6
EMI = electromagnetic interference.
7
RFI = radio frequency interference.
Contact and Site Information
Use the following worksheet to record contact and site information.
Table 17: Contact and Site Information
Contact person
Contact phone
Contact e-mail
Building/site name
Data center location
Floor location
Address (line 1)
Address (line 2)
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
59
Site Planning and Maintenance Records
Contact and Site Information

Cisco UCS 6454 Specifications

General

Product Type	Fabric Interconnect
Ports	54
USB Ports	1 x USB 2.0
Form Factor	1 RU
Management	Cisco UCS Manager
Port Types	FCoE, FC
Downlink Ports	48 x 10/25 Gbps SFP28
Management Ports	1 x 1 Gbps RJ45
Console Ports	1 x RJ45
Latency	Less than 1 microsecond
Redundancy	Redundant power supplies and fans
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5 to 95% relative humidity, noncondensing
Power Supply	650W AC, hot-swappable
