Cisco UCS 6454 User Manual

Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 1-meterQSFP-H40G-AOC1M
Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 2-meterQSFP-H40G-AOC2M
Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 3-meterQSFP-H40G-AOC3M
Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 5-meterQSFP-H40G-AOC5M
Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 7-meterQSFP-H40G-AOC7M
Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 10-meterQSFP-H40G-AOC10M
Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 15-meterQSFP-H40G-AOC15M
100 GbE QSFP Cables
Cisco 100GBASE SFP28 passive direct-attach copper cable, 1 meter
QSFP-100G-CU1M
Cisco 100GBASE SFP28 passive direct-attach copper cable, 3 meterQSFP-100G-CU2M
Cisco 100GBASE SFP28 passive direct-attach copper cable, 5 meterQSFP-100G-CU3M
Cisco 100GBASE SFP28 active direct-attach optical cable, 1 meterQSFP-100G-AOC1M
Cisco 100GBASE SFP28 active direct-attach optical cable, 2 meterQSFP-100G-AOC2M
Cisco 100GBASE SFP28 active direct-attach optical cable, 3 meterQSFP-100G-AOC3M
Cisco 100GBASE SFP28 active direct-attach optical cable, 5 meterQSFP-100G-AOC5M
Cisco 100GBASE SFP28 active direct-attach optical cable, 7 meterQSFP-100G-AOC7M
Cisco 100GBASE SFP28 active direct-attach optical cable, 10 meterQSFP-100G-AOC10M
Cisco 100GBASE SFP28 active direct-attach optical cable, 15 meterQSFP-100G-AOC15M
Cisco 100GBASE SFP28 active direct-attach optical cable, 20 meterQSFP-100G-AOC20M
Cisco 100GBASE SFP28 active direct-attach optical cable, 25 meterQSFP-100G-AOC25M
Cisco 100GBASE SFP28 active direct-attach optical cable, 30 meterQSFP-100G-AOC30M
SFP Fibre Channel Transceivers
The UCS 6454 Fabric Interconnect supports the SFP Fibre Channel transceivers listed below.
Table 5: SFP Fiber Channel Transceivers
DescriptionModel
8-Gbps Fibre Channel SW SFP+, LCDS-SFP-FC8G-SW
8-Gbps Fibre Channel LW SFP+, LCDS-SFP-FC8G-LW
16-Gbps Fibre Channel SW SFP+, LCDS-SFP-FC16G-SW
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
12
Product Overview
SFP Fibre Channel Transceivers

Cisco UCS 6454 Specifications

General

Product Type	Fabric Interconnect
Ports	54
USB Ports	1 x USB 2.0
Form Factor	1 RU
Management	Cisco UCS Manager
Port Types	FCoE, FC
Downlink Ports	48 x 10/25 Gbps SFP28
Management Ports	1 x 1 Gbps RJ45
Console Ports	1 x RJ45
Latency	Less than 1 microsecond
Redundancy	Redundant power supplies and fans
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5 to 95% relative humidity, noncondensing
Power Supply	650W AC, hot-swappable
