Cisco UCS 6454 User Manual

CONTENTS
Product Overview 1
CHAPTER 1
Cisco UCS 6454 Fabric Interconnect Overview 1
Cisco UCS 6454 Fabric Interconnect 1
Ports on the Cisco UCS 6454 Fabric Interconnect 2
Port Numbering 4
Power Supplies 5
Fan Modules 6
HA Ports and LEDs 6
Management Port LEDs 7
System Environment LEDs 7
Port LEDs 8
L1 and L2 Port LEDs 8
Supported Transceivers 8
SFP 1-Gigabit Transceivers 9
SFP+ Transceivers and SFP+ Copper Cables 9
QSFP Transceivers and Cables 11
SFP Fibre Channel Transceivers 12
Installing the Cisco UCS Fabric Interconnect 15
CHAPTER 2
Preparing for Installation 15
Considerations and Warnings 15
Installation Options 16
Airflow Considerations 16
Fabric Interconnect Weight 16
Installation Guidelines 16
Required Equipment 17
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
iii

Cisco UCS 6454 Specifications

General

Product Type	Fabric Interconnect
Ports	54
USB Ports	1 x USB 2.0
Form Factor	1 RU
Management	Cisco UCS Manager
Port Types	FCoE, FC
Downlink Ports	48 x 10/25 Gbps SFP28
Management Ports	1 x 1 Gbps RJ45
Console Ports	1 x RJ45
Latency	Less than 1 microsecond
Redundancy	Redundant power supplies and fans
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5 to 95% relative humidity, noncondensing
Power Supply	650W AC, hot-swappable
