Redundant Distribution
Switch (Port Channel
Peer and Downlink)
Single Distribution
Switch (Single Port
Channel Downlink)
Single Distribution
Switch (Single Downlink)
Setting
RPVST+RPVST+RPVST+Spanning Tree Mode
Mode TransparentMode TransparentMode TransparentVTP
EnabledEnabledEnabledUDLD
Recovery mode set to
Auto
Recovery mode set to
Auto
Recovery mode set to
Auto
Error Disable Recovery
Source Destination IPSource Destination IPSource Destination IPPort Channel Load
Balance
Version 2Version 2Version 2SSH
EnabledEnabledEnabledSCP
EnabledEnabledEnabledVTY Access to Switch
EnabledEnabledEnabledService Timestamp
The following VLANs are
created:
• Default VLAN
• Data VLAN
• Voice VLAN
• Management VLAN
The following VLANs are
created:
• Default VLAN
• Data VLAN
• Voice VLAN
• Management VLAN
The following VLANs are
created:
• Default VLAN
• Data VLAN
• Voice VLAN
• Management VLAN
VLAN
Layer 3 settings
configured on the
management port, based
on Quick Setup
Layer 3 settings
configured on the
management port, based
on Quick Setup
Layer 3 settings
configured on the
management port, based
on Quick Setup
Management Interface
QoS Policy for
Distribution defined
QoS Policy for
Distribution defined
QoS Policy for
Distribution defined
QoS Policy
Selected uplink ports
connect to other
distribution or core
switches
Selected uplink ports
connect to other
distribution or core
switches
Selected uplink ports
connect to other
distribution or core
switches
Uplink Interfaces
Downlink connections to
access switches
configured in Trunk mode
Downlink connections to
access switches
configured in Trunk mode
Downlink connections to
access switches
configured in Trunk mode
Downlink Interfaces
Port-channel to core or
distribution created
Port-channel to core or
access created
Port-channel to core
created
Port-channel
Catalyst 3850 Switch Hardware Installation Guide
97OL-26779-05
Configuring the Switch
Configuring Your Device Based on a Site Profile
