Chapter 1 Overview
Rear Panel
1-8
Cisco VG248 Analog Phone Gateway Hardware Installation Guide
78-13154-01
Rear Panel
The rear panel of the VG248 includes the power connector (see Figure 1-3). The
VG248 has a single AC inlet requiring 100- 240 VAC, 50-60 Hz. The VG248
draws approximately 176W at 100v in its maximum load condition.
Figure 1-3 VG248 Rear Panel
Table 1-5 Ethernet Port Connector Pinouts
Pin Number Function
1TD+
2TD-
3RD+
4—
5—
6RD-
7—
8—
1 Power connector
1
58953
