Page #20 background imageLoading...
Page #20 background image
1-3
Cisco VG350 Voice Gateway Hardware Installation Guide
OL-25970-01
Chapter 1 Overview of the Cisco VG350 Voice Gateway
Interfaces and Service Capabilities
Configuration Options
The following configuration options are available for Cisco VG350 Voice Gateway:
Table 1-1 Configuration Options Possible with Cisco VG350 Voice Gateway with the Double-Wide
High Density Analog Service Module (DWSM)
Interfaces and Service Capabilities
Table 1-2 lists the built-in interface ports for the Cisco VG350.
Table 1-2 Built-in Interfaces for the Cisco VG350
1 USB serial console port 6 USB0 and USB1 (1, Top)
2 RJ-45 serial console port 7 Ground
3 SFP1 and SFP2 (2, Top) 8 CompactFlash 0 and 1 (0, Far right)
4 10/100/1000 Ethernet ports GE 0/1 and GE
0/2 (GE 0/2,Top)
9 SM-D-72FXS Service Module
5 10/100/1000 Ethernet port GE 0/0 10 SM-D-48FXS-E Service Module
Configuration
VG350
SM 1 SM 2 Total number of ports
1 SM-D-72FXS SM-D-72FXS 144
2 SM-D-72FXS SM-D-48FXS-E 120
4 SM-D-48FXS-E SM-D-48FXS-E 96
Data Ports Management Ports
10/100/1000
GE RJ-45
10/100/1000
SFP USB Type A
Console Serial,
RJ-45
Console Serial,
Mini-USB
(Type B)
Auxiliary,
RJ-45
Cisco VG350 Voice
Gateway
3
1
221 1 1
1. One RJ-45 with two GE SFPs or three RJ-45 GEs.
