C-8
Catalyst 3560 Switch Hardware Installation Guide
OL-6337-07
Appendix C Connecting to DC Power
Connecting to DC Power
Figure C-10 Inserting the Terminal Block in the Block Header
Step 9 Remove the tape from the circuit-breaker switch handle, and move the circuit-breaker handle to the
on position.
1 Tie wrap 2 Terminal block
274669
