Chapter 1 Product Overview
Features
Supported SFP modules:
• 100BASE-BX10 (only Catalyst 3560 8- and 12-port switches)
• 100BASE-FX
• 100BASE-LX (only Catalyst 3560 8- and 12-port switches)
• 1000BASE-BX10
• 1000BASE-LX
• 1000BASE-SX
• 1000BASE-T (only Catalyst 3560 24- and 48-port switches)
• 1000BASE-ZX
• Coarse Wavelength-Division Multiplexing (CWDM)
• SFP module patch cable. (CAB-SFP-50CM=.) Switches running Cisco IOS Release 12.2(25)SEB or
later support this patch cable.
Table 1-1 Catalyst 3560 Switch Model Descriptions
Switch Model Description
FastEthernet
Catalyst 3560-24PS 24 10/100 Power over Ethernet (PoE) ports and 2 small form-factor
pluggable (SFP) module slots
Catalyst 3560-24TS-S 24 10/100 ports and 2 SFP module slots
Catalyst 3560-48PS 48 10/100 PoE ports and 4 SFP module slots
Catalyst 3560-48TS-S 48 10/100 ports and 4 SFP module slots
Catalyst 3560V2-24PS 24 10/100 PoE ports and 2 SFP module slots
Catalyst 3560V2-24TS 24 10/100 ports and 2 SFP module slots
Catalyst 3560V2-48PS 48 10/100 PoE ports and 4 SFP module slots
Catalyst 3560V2-48TS 48 10/100 ports and 4 SFP module slots
Catalyst 3560V2-24TS-SD 24 10/100 PoE ports and 2 SFP module slots (DC power)
Catalyst 3560-8PC
1
1. The Catalyst 3560-8PC and the Catalyst 3560-12PC-S switches are smaller than the other Catalyst 3560 switches. They can
be mounted with a magnet, have security lock slots, and do not have a fan or an RPS port.
8 10/100 PoE ports and 1 dual-purpose port (one 10/100/1000BASE-T
copper port and one SFP module slot)
Catalyst 3560-12PC-S
1
12 10/100 PoE ports and 1 dual-purpose port
Gigabit Ethernet
Catalyst 3560G-24PS 24 10/100/1000 PoE ports and 4 SFP module slots
Catalyst 3560G-24TS 24 10/100/1000 ports and 4 SFP module slots
Catalyst 3560G-48PS 48 10/100/1000 PoE ports and 4 SFP module slots
Catalyst 3560G-48TS 48 10/100/1000 ports and 4 SFP module slots
