A-3
Catalyst 3560 Switch Hardware Installation Guide
OL-6337-07
Appendix A Technical Specifications
Table A-4 Specifications for the Catalyst 3560-24TS-S Switch
Power Requirements
AC input voltage 100 to 240 VAC (autoranging) 450 to 190 mA,
50 to 60 Hz
DC input voltages for RPS 675 + 12 V @ 5 A
Power consumption 45 W
Maximum power consumption 45 W, 154 BTUs per hour
Maximum power dissipation 0.075 KVA
Physical Dimensions
Weight 8.5 lb (3.9 kg)
Dimensions (H x D x W) 1.73 x 11.81 x 17.5 in. (4.39 x 30 x 44.45 cm)
Table A-5 Specifications for the Catalyst 3560-48TS-S Switch
Power Requirements
AC input voltage 100 to 240 VAC (autoranging)
650 to 270 mA, 50 to 60 Hz
DC input voltages for RPS 675 + 12 V @ 5 A
Maximum power consumption 65 W
Maximum power dissipation 65 W, 222 BTUs per hour
Power rating 0.110 KVA
Physical Dimensions
Weight 9.1 lb (4.1 kg)
Dimensions (H x D x W) 1.73 x 11.81 x 17.5 in. (4.39 x 30 x 44.45 cm)
Table A-6 Specifications for the Catalyst 3560-8PC and Catalyst 3560-12PC Switches
Power Requirements
AC input voltage 100 to 240 VAC (autoranging)
2.5 to 1.3 A, 50 to 60 Hz
Maximum power consumption 204 W
Maximum power dissipation 80 W, 12 BTUs per hour
Power rating 0.2 KVA
Power over Ethernet
Up to 124-W switch maximum
Physical Dimensions
Weight 5 lb (2.3 kg)
Dimensions (H x D x W) 1.73 x 9.1 x 10.6 in. (4.4 x 23 x 26.9 cm)
