A-6
Catalyst 3560 Switch Hardware Installation Guide
OL-6337-07
Appendix A Technical Specifications
DC input voltages for
RPS 2300 and 675
+12 V @14 A and –48 V @7.8 A
Power consumption 560 W
Power dissipation 220 W, 690 BTUs per hour
Power rating 0.56 kVA
Power over Ethernet
Range from 4 to 15.4 W per port, up to 370 W switch maximum
Physical Dimensions
Weight 11.3 lb (5.1 kg)
Dimensions (H x W x D) 1.73 x 17.5 x 11.8 in. (4.4 x 44.5 x 30.1 cm)
Table A-12 Specifications for the Catalyst 3560V2-48TS and 3560V2-24TS Switch
Environmental Ranges
Operating temperature 32 to 113°F (0 to 45°C)
Storage temperature –13 to 158°F (–25 to 70°C)
Relative humidity 10 to 85% (noncondensing)
Operating altitude Up to 10,000 ft (3049 m)
Storage altitude Up to 15,000 ft (4573 m)
Power Requirements
AC input voltage 100 to 240 VAC (autoranging)
0.8 to 1.5 A, 50 to 60 Hz
DC input voltages for
RPS 2300 and 675
+12 V @17 A
Power consumption 180 W, 615 BTUs per hour
Power rating 0.180 kVA
Physical Dimensions
Weight 8.5 lb (3.9 kg)
Dimensions (H x W x D) 1.73 x 11.81 x 17.5 in. (4.4 x 30 x 44.45 cm)
Table A-13 Specifications for the Catalyst 3560V2-24TS-SD Switch
Environmental Ranges
Operating temperature 32 to 113°F (0 to 45°C)
Storage temperature –13 to 158°F (–25 to 70°C)
Relative humidity 10 to 85% (noncondensing)
Operating altitude Up to 10,000 ft (3049 m)
Storage altitude Up to 15,000 ft (4573 m)
Table A-11 Specifications for the Catalyst 3560V2-48PS and 3560V2-24PS Switch (continued)
Environmental Ranges
