Citizen CL-S521 User Manual

32
Chapter 2 Printer Operation
Menu Setting Table
Global Cong menu - allows you to switch between 3 complete ‘cong sets’ contained within the printer.
Page Setup Menu - allows you to change settings related to the media or print quality.
System Setup Menu - allows you to change settings for the printer hardware and basic control systems.
After Print Menu - changes how the printer reacts after the label has been printed.
Interfaces - changes interface parameters such as baud rate.
Menu Setting

Datamax® Emulation
Top Menu Sub Menu Default Menu Remarks
Global
conguration
– Cong Set 1 Cong Set 1
Cong Set 2
Cong Set 3
Sets the Cong Set.
Page Setup Print Speed 4 IPS 2 to 6 IPS [For CL-S521]
Printing speed setting.
(2 to 4 IPS with optional peeler.)
4 IPS 2 to 4 IPS [For CL-S531]
Printing speed setting.
Print Darkness 10 00 to 30 Print darkness setting
(printhead temperature)
Darkness Adjust 0 -10 to 10 Darkness command adjustment
Continuous Media
Length
4.00 inch
101.6 mm
0.25 to 32.00 inch
6.40 to 812.8 mm
Setting default length of continuous media,
if selected. ; the lower line is in metric mode.
Vertical Position 0.00 inch
0.0 mm
-1.00 to 1.00 inch
-25.4 to 25.4 mm
Print start position adjustment
Horizontal Shift 0.00 inch
0.0 mm
-1.00 to 1.00 inch
-25.4 to 25.4 mm
Horizontal printing location adjustment
Vertical Image Shift 0.00 inch
0.0 mm
0.00 to 32.00 inch
0.0 to 812.8 mm
Adjust the o set value in vertical when
mapping data on a RAM.
Media Sensor See Through See Through
Reect
None
Label sensor selection
Small Media
Adjustment
O On
O
Setting for small labels
Small Media Length 1.00 inch
25.4 mm
0.25 to 1.00 inch
6.40 to 25.4 mm
Setting length of small label media
System Setup
Sensor Level 1.5 V 0.0 V to 3.3 V Setting the threshold of the sensor
Paper End Level 2.80 V 0.01 V to 3.00 V Sets the paper end level.
Error Reporting On Printing
On Printing
Immediate
Setting for error report.
Buzzer Select On On
O
Setting buzzer sounding conditions
Metric/Inch Inch Inch
mm
Setting the units used
Max Media Length 10.00 inch
254.0 mm
1.00 to 50.00 inch
25. 4 to 1270.0 mm
Setting the maximum label length
Mode Settings
[Datamax® Emulation]

Citizen CL-S521 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 DPI
PC connected	Yes
Standard interfaces	USB 1.1, Serial
Optional connectivity	Ethernet, Serial (RS-232)
USB 1.1 ports quantity	1
Connectivity technology	Wired
Flash memory	4 MB
Internal memory	16 MB
Compatible operating systems	Windows 7/XP/2003/2008/Vista
Form factor	Desktop
Core diameter	25 mm
Media thickness	0.0635 - 0.254 mm
Maximum media length	1625.6 mm
Maximum roll diameter	125 mm
Supported paper width	12.5 - 118.1 mm
Media thickness (imperial)	0.0025 - 0.01 \
Supported paper width (imperial)	0.50 - 4.65 \
Product color	Gray
Housing material	Metal, Plastic

Weight and Dimensions

Depth	289 mm
Width	231 mm
Height	183 mm
Weight	3600 g
