Citizen CL-S521 User Manual

47
Appendixes
Specications
Item Description
Printing Printing method Direct thermal
Resolution Main scanning line density: 203 dots/inch (8 dots/mm) (CL-S521)
300 dots/inch (11.8 dots/mm) (CL-S531)
Sub- scanning line density: 203 dots/inch (8 dots/mm) (CL-S521)
300 dots/inch (11.8 dots/mm) (CL-S531)
Head 864 dots (printable dots: 832 dots) (CL-S521)
Head 1275 dots (printable dots: 1240 dots) (CL-S531)
Max. print width 104 mm (CL-S521)
105 mm (CL-S531)
4.1 inch
Max. print length 812.8 mm 32 inch
Print density Print density is adjustable with software
Printing speed Printing speed setting [For CL-S521]
6, 5, 4, 3 or 2 inches per second
• 4, 3 or 2 inches per second when the optional peeler is used.
[For CL-S531]
4, 3 or 2 inches per second
Print mode Batch mode Normal printing (single or multiple sheets)
Tear o mode Feeds back media to the tear-o position after printing is completed.
Cut mode
*1
Prints while cutting at designated sheet units.
The following two kinds of cut mode operations are done.
• Backfeed
• Cut through (Cut through refers to stopping present printing
to cut the previous label when it reaches the cut position. After
cutting, printing restarts but a gap may be created at the seam of
the printing at this time.)
Peel mode
*1
Peels labels from the liners after printing them.
Media
*2
Types of media Roll, fanfold
(continuous media, die-cuts, continuous tags. paper or tickets)
Kinds of media Thermal-transfer media
Recommended media Heat-transfer media: label media (150LA-1 Ricoh),
tag media (130LHB Ricoh)
Max. media width 118.0 mm 4.65 inch
Min. media width 19.5 mm 0.77 inch
Min. label width 19.5 mm 0.77 inch
Min. label pitch
*3
6.35 mm 0.25 inch
Max. media thickness 0.254 mm 0.01 inch
Max. media length 812.8 mm 32 inch
Min. media length 6.35 mm 0.25 inch
Min. media thickness 0.0635 mm 0.0025 inch
On-board roll media
diameter
Max. external diameter: 127 mm 5 inch
Media core: 25.4 to 76 mm 1 to 3 inch

Citizen CL-S521 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 DPI
PC connected	Yes
Standard interfaces	USB 1.1, Serial
Optional connectivity	Ethernet, Serial (RS-232)
USB 1.1 ports quantity	1
Connectivity technology	Wired
Flash memory	4 MB
Internal memory	16 MB
Compatible operating systems	Windows 7/XP/2003/2008/Vista
Form factor	Desktop
Core diameter	25 mm
Media thickness	0.0635 - 0.254 mm
Maximum media length	1625.6 mm
Maximum roll diameter	125 mm
Supported paper width	12.5 - 118.1 mm
Media thickness (imperial)	0.0025 - 0.01 \
Supported paper width (imperial)	0.50 - 4.65 \
Product color	Gray
Housing material	Metal, Plastic

Weight and Dimensions

Depth	289 mm
Width	231 mm
Height	183 mm
Weight	3600 g
