33
Chapter 2 Printer Operation
Top Menu Sub Menu Default Menu Remarks
Settings Lock O On
O
When on, prevents software commands
from changing the values set by the VuePrint
menu
Keyboard Lock O On
O
Prevents the control panel from aecting
the printer’s conguration. (User “lock-out”)
Control Code
STD STD
ALT
ALT-2
Selects between the Standard STX control
code or the “Alternative” code. Sometimes
called “AS400 mode”.
Emulation Select DM4 DMI
DM4
DPP
ZPI2
Selects DataMax®/Zebra® compatibility
DMI: DataMax® IClass
DM4: DataMax® 400 like
DPP: DataMax® Prodigy Plus®
ZPI2: Zebra® Emulation
Emulation Auto
Detect
On On
O
Full Auto
Selects the detection of Datamax® and
Zebra® emulation.
After Print AutoCongure On On
O
Optional auto congure
On .....Auto congure eective.
If a peeler unit or auto-cutter is
installed, each mode is automatically
set regardless of the “function select”
setting.
O ....Auto congure ineective.
When a peeler unit or auto-cutter is
installed but has not been started, it
is o and the operation is selected by
“Function select”.
Function Select Tear O
Tear
Peel On*
Cut On*
Selects the type of options installed and
adjusts the “paper stop” position accordingly.
For example, the position where the label
stops in “Tear” mode is dierent to that in
“Peel On” mode.
Cutter Action* Backfeed Backfeed
Through
Cutter operating method setting
Backfeed: it feeds back after each cutting
operation.
Through: when the number copied = n, the
back end of sheet 1 to n-1 passes through,
and the back end of the nal page that is a
single sheet is copied and fed back.
Paper Position 0.00 inch
0.0 mm
Peel/Cut/Tear O
0.00 to 2.00 inch
0.0 to 50.8 mm
Peel/Cut/Tear On
-1.00 to 1.00 inch
-25.4 to 25.4 mm
The stop position can be ne tuned using
this menu setting. The general stop position
is selected depending on the “Function”
selected above.
* Eective only when the optional unit is attached.
Mode Settings
[Datamax® Emulation]
To Next Page
