Citizen CLP-621 Technical Manual

3-6. Adjustments
CLP-621 & CLP-631 3-46
(1-1) Ribbon slant elimination adjustment for user (FRONT)
This front side adjustment is required in the following cases:
• Ribbon slant occurs, resulting in ribbon wrinkle.
• Ribbon Sensor F Unit is replaced or reassembled.
1. Turn the Ribbon Left-Right Balance Adjustment Knobs (Front) to the center of the scale.
2. Turn the Ribbon Left-Right Balance Adjustment Knob (Rear) to the center of the scale.
Ribbon Left-Right Balance
Adjustment Knob (Front)
Ribbon Left-Right Balance
Adjustment Knob (Rear)
Ribbon
3. Turn the Ribbon Left-Right Balance Adjustment Knob (Front) to remove ribbon wrinkle.
4. If ribbon slant is not removed yet, proceed to the next item, (1-2).
(1-2) Ribbon slant elimination adjustment for user (REAR)
This rear side adjustment is required in the following cases:
• Ribbon slant occurs, resulting in ribbon wrinkle.
• Ribbon Sensor R Unit is replaced or reassembled.
1. Turn the Ribbon Left-Right Balance Adjustment Knob (Rear) and remove ribbon
wrinkle.
2. If ribbon slant is not removed, repeat above item, (1-1).

Citizen CLP-621 Specifications

General

USB port	No
RS-232 interface	Yes
Optional connectivity	Ethernet
USB 1.1 ports quantity	1
USB 2.0 ports quantity	0
Connectivity technology	Wired
Flash memory	2 MB
Certification	UL, C-UL, FCC class A, CCC, CE Marking
Internal memory	8 MB
Number of fonts	2
Built-in barcodes	PDF417, UPC-A, UPC-E
Built-in processor	32 Bit RISC
Mean cycles between failures (MCBF)	1000
Power consumption	2400 mA
Power requirements	100 - 240V, 50 / 60Hz
Compatible operating systems	Windows 2000, XP, Vista
Core diameter	25.4 mm
Ribbon length	360 m
Media thickness	0.0635 - 0.254 mm
Maximum label length	812 m
Maximum roll diameter	127 mm
Supported paper width	19.5 - 118 mm

Weight and Dimensions

Depth	114 mm
Width	91 mm
Height	104 mm
