1-1. General Specifications
1-1. General Specifications
1-3 CLP-621 & CLP-631
Printing
Printing method Thermal transfer/Direct thermal
Main scanning line density: 203 dots/inch (8 dots/mm) (CLP-621)
300 dots/inch (11.8 dots/mm) (CLP-631)
Sub-scanning line density: 203 dots/inch (8 dots/mm) (CLP-621)
300 dots/inch (11.8 dots/mm) (CLP-631)
Resolution
Head 864 dots (effective dots: 832 dots) (CLP-621)
Head 1275 dots (effective dots: 1240 dots) (CLP-631)
Max. print width 104 mm (CLP-621)
105 mm (CLP-631)
4.1 inch
Max. print length 812.8 mm 32 inch
Print density Print density is adjustable with software
Printing speed setting 4, 3 or 2 inches per second.
Print mode
Batch mode Normal printing (single or multiple sheets)
Tear off mode Feeds back media to the tear-off position after printing is completed.
Cut mode *
1
Prints while cutting at designated sheet units.
The following two kinds of cut mode operations are available.
• Backfeed
• Cut through
(Cut through refers to stopping present printing to cut the previous
label when it reaches the cut position. After cutting, printing restarts
but a gap may be created at the seam of the printing at this time.)
Peel mode*
2
Peels labels from the liners after printing them.
Media
Types of media Roll, fanfold
(continuous media, die-cuts, continuous tags, paper or tickets)
Recommended media Thermal-transfer: label media (RP050 Ricoh)
Direct thermal media: label media (140LAB Ricoh)
tag media (TB2E0V, Mitsubishi Paper)
Max. media width 118.0 mm 4.65"
Min. media width 19.5 mm 0.77"
Min. label width 19.5 mm 0.77"
Min. label pitch*
3
6.35 mm 0.25"
*1,*2: Options can be separately purchased.
*3: When a media pitch of less than 1" is used, set the "Small Media Adjustment" setting in
the "Page Setup" menu to "ON".
