Chapter 5. Parts Lists
CLP-621 & CLP-631 5-4
PARTS LIST for CLP-621 & CLP-631 TITLE: Recommended Spare Parts List Sheet No. 1/1
Rev. No. 0
Maint. Class
Item
No.
Location Part No. Part Name
Q'ty/
Unit
Worn Casual
Remarks @
1 2-8 JM66802-0 Unit, Main PCB (With ROM)-IT 1
For CLP-621/CSA
2 2-8 JM66821-0 Unit, Main PCB (With ROM)-IT 1
For CLP-631/CSA
3 2-8 JM66801-0 Unit, Main PCB (With ROM)-MT 1 For CLP-621/CSE
4
2-8 JM66819-0 Unit, Main PCB (With ROM)-MT 1
For CLP-631/CSE
5 2-8 JM66809-0 Unit, Main PCB (With ROM)-ZI 1
For CLP-621Z/CSA*
1
6 2-8 JM66823-0 Unit, Main PCB (With ROM)-631ZI 1
For CLP-631Z/CSA*
1
7 2-8 JM66808-0 Unit, Main PCB (With ROM)-ZM 1
For CLP-621Z/CSE*
1
8 2-8 JM66822-0 Unit, Main PCB (With ROM)-631ZM 1
For CLP-631/CSE*
1
9 2-33 JM66811-1 Unit, Power Supply (100V) PB F 1
For CSA
10 2-33
JM66816-1 Unit, Power Supply (200V) PB F
1
For CSE
11 3-15 JM22701-0 SA, Platen 1
12 3-18 JM66715-1 SA, Head Up Sensor PCB 1
13 4-5 JM14705-0 SA, Head 1
For CLP-621
14 4-5 JM14706-0 SA, Head 1
For CLP-631
15 5-1 JM25701-0 SA, Motor 1
16 5-14 JM66730-1 SA, Reflective Sensor PCB 1
17 6-9 JM66725-0 SA, Transparent Sensor PCB 1
18 8-5 JM66740-0 SA, Ribbon Main PCB 1
19 8-8 JM35703-0 SA, Ribbon Motor R 1
20 8-9 JM35702-0 SA, Ribbon Motor F 1
21 8-20 JM68705-0 SA, Tension Sensor 2
*1: CLP-621Z & CLP-631Z are identical to CLP-621 & CLP-631 except for the firmware and character generator.
To Next Page
