Citizen CLP-621 Technical Manual

Chapter 5. Parts Lists
CLP-621 & CLP-631 5-34
PARTS LIST for CLP-621 & CLP-631 TITLE: Ribbon Unit Sheet No. 2/3
Drawing No. 8 Rev. No. 0
Location Part Name Part No.
Q'ty/
Unit
Remarks @
8-21 Bush 2, Ribbon Guide Roller JM31202-0 4
-22 Screw, BH, M3.0x3 (NI) E00530-030WF 8
-23 Screw, No.0, TFH (BH), M2x4 (NI) E15920-040WF 4
-24 SA, Ribbon Sensor Frame F JM34702-1 1
-25 SA, Ribbon Tension Shaft F JM34715-0 1
-26 Sheet, Static Eliminator 621 JM29909-0 1
-27 SA, Tension Adjust Lever R JM34712-0 1
-28 SA, Ribbon Sub Adjust Lever R JM34714-0 1
-29 Spring R, Ribbon Tension JM33605-0 2
-30 SA, Ribbon Sensor Frame R JM34703-1 1
-31 SA, Ribbon Tension Shaft R JM34716-0 1
-32 Screw, No.0, THF, M2x3 (NI) E03920-030WF 2
-33 Plate, Ribbon Washer JM34122-0 2 CC-0205-05B
-34 SA, Holder R Shaft JM31701-0 2
-35 Spring, Ribbon Return JM33601-0 2
-36 Gear 5R, Ribbon JM30204-0 1
-37 Gear 4, Ribbon JM30203-1 2
-38 Gear 1, Ribbon JM30201-0 2
-39 Gear 3, Ribbon JM30205-0 2
-40 E-Ring, 4 E60340-000F 2

Citizen CLP-621 Specifications

General

USB port	No
RS-232 interface	Yes
Optional connectivity	Ethernet
USB 1.1 ports quantity	1
USB 2.0 ports quantity	0
Connectivity technology	Wired
Flash memory	2 MB
Certification	UL, C-UL, FCC class A, CCC, CE Marking
Internal memory	8 MB
Number of fonts	2
Built-in barcodes	PDF417, UPC-A, UPC-E
Built-in processor	32 Bit RISC
Mean cycles between failures (MCBF)	1000
Power consumption	2400 mA
Power requirements	100 - 240V, 50 / 60Hz
Compatible operating systems	Windows 2000, XP, Vista
Core diameter	25.4 mm
Ribbon length	360 m
Media thickness	0.0635 - 0.254 mm
Maximum label length	812 m
Maximum roll diameter	127 mm
Supported paper width	19.5 - 118 mm

Weight and Dimensions

Depth	114 mm
Width	91 mm
Height	104 mm
