ENGINE
AUXILIARY EQUIPMENT DRIVE BELT
Engine: KFU
B1BP2LTC
Tools.
[1] Plyers for removing plastic pegs : 7504 -T
[2] Belt tension measuring instrument (SEEM) : 4122 -T
Removing.
Raise and support the vehicle, front wheels hanging.
Disconnect the battery.
Remove the front RH wheel and the front RH splash-shield, using tool [1].
V
ehicle without air conditioning.
Removing.
Slacken the tension, screw (2), screw (3) and screw (1).
Push back the alternator towards the engine.
Remove the auxiliary equipment drive belt.
Refitting.
Refit the auxiliary equipment drive belt.
Respect the following sequence:
- Crankshaft pinion, alternator pulley.
- Position tool [2] on the belt. Tighten the screw (1) to tension the belt to 55 ± 3 SEEM units.
- Tighten screw (3), screw (2).
- Remove tool [2].
- Complete the refitting in the opposite order to removal.
B1BP2LSC
