CKD AX0180 - Changing the Displayed Paraｓmeter to Another Parameter; Changing the Input Unit of Parameter 3, 8, 9, 16, 19, 37, 45, 46

[SMB-66E]
－ 26 －
OPERATION
2
2.6.1.1 Changing the displayed parameter to another parameter
There are the following two methods for changing the parameter display mode.
a) Entering the parameter number
When the cursor is located at the parameter
number, enter the desired parameter number
and press .
b) Pressing
or to switch the display
When the cursor is located at the parameter
number, press
or to display the
previous or next parameter.
2.6.1.2 Changing the input unit of parameter 3, 8, 9, 16, 19, 37, 45, 46
1) Select parameter (PRM 3, 8, 9, 16, 19, 37, 45,
46).The initial unit is pulses.
2) When the cursor is located at the parameter
number, press
.
The unit changes to angle (°).
3) Press
to return to pulses.
★
Changing the displayed parameter
number to "5"
Enter "5"
and press
ＣＡＭ ＣＵＲＶ Ｐ０１
［１］ＭＳ
ＨＭＥＲＴＮ ＳＰＤ Ｐ０５
［ １．０］ＲＰＭ
ＨＭＥＰＯＳＩ ＯＦＳＴ Ｐ０３
［ ０］ＰＬＳ
ＨＭＥＰＯＳＩ ＯＦＳＴ Ｐ０３
［ ０．０００］゜
ＣＡＭ ＣＵＲＶ Ｐ０１
［１］ＭＳ
ＭＣ２ ＬＳＰＤ ＴＭ Ｐ０２
［ １．００］ＳＥＣ
ＮＯＴＣＨ１ Ｑ Ｐ７１
［ １．０］
ＩＮＴＧＲ ＧＡＩＮ Ｐ７２
［ １．０］
