2.6.5.2 PROFIBUS-DP Communication
1） Select “6 PROFI” from the parameter
menu and press
.
2） Currently set station number is displayed.
The station number can be set for
PROFIBUS-DP communication.
It is not necessary to set the baud rate
since it is set through the auto baud rate
function.
Press
during data entry to display
the setting range for that item.
Press
to return to the original screen.
※ When a value outside of the setting range
is entered, the message on the right
is displayed.
Press
MODE
after configuring the settings.
3） When
MODE
is pressed, the
message on the right is displayed.
c） Selecting “Y”
After the configured settings are stored
in the driver, the message on the right
is displayed, and the parameter menu
is displayed again.
※
※※
※ Control power must be restarted to
validate the settings. Press
after confirming the following message.
d） Selecting “N”
The parameter menu is displayed again
without storing the configured settings
in the driver.
ＰＲＯＦＩＢＵＳ
ＳＴ ＮＯ． ［ ０］
ＰＲＯＦＩＢＵＳ
ＳＴ ＮＯ． ［ ０］
ＰＲＯＦＩＢＵＳ ＲＮＧ
ＳＴ ＮＯ． ０～１２５
ＰＲＯＦＩＢＵＳ
ＲＥＧＩＳＴＥＲＥ？ ［Ｙ／Ｎ］
ＰＲＯＦＩＢＵＳ
＊ＲＥＧＩＳＴＥＲＥＤ＊
ＩＮＰＵＴＯ ＡＧＡＩＮ
ＳＴ ＮＯ． ［９９９］
ＰＡＲＡ
←５ＲＡＭ ６ＰＲＯＦＩ
ＴＵＲＮ ＤＲＩＶＥＲ ＯＦＦ
ＴＵＥＮ ＯＮ ＡＧＡＩＮ
