OPERATION
2
2.7.12 Offset zeroing procedure
1) Select "3 PARA" from the mode selection menu.
2) Select "1 READ" from the parameter mode menu.
3) While the cursor is located at the parameter
number, enter "3" and press
.
The origin offset amount entry screen is
displayed.
4) Next, press
. The cursor moves to the
position of the setting. Enter "0" and press
.
5) Press
MODE
to return to the menu, and select
"3 STORE" and press
.
The offset amount is reset to zero.
※
※※
※ The new origin offset amount becomes valid
after the control power is turned off then on
again or after a home return is executed.
★Suppose that the origin offset amount is
"98000 pulses."
Enter "3"
and press
Enter "0"
and press
MODE
ＭＯＤＥ ＳＥＬＥＣＴ
←２ＤＩＳＰＬＡＹ ３ＰＡＲＡ→
ＰＡＲＡ
１ＲＥＡＤ ２ＣＮＴ →
ＣＡＭ ＣＵＲＶ Ｐ０１
［１］ＭＳ
ＨＭＥＰＯＳＩ ＯＦＳＴ Ｐ０３
［ ９８０００］ＰＬＳ
ＨＭＥＰＯＳＩ ＯＦＳＴ Ｐ０３
［ ９８０００］ＰＬＳ
ＨＭＥＰＯＳＩ ＯＦＳＴ Ｐ０３
［ ０］ＰＬＳ
ＰＡＲＡ
←２ＣＮＴ ３ＳＴＯＲＥ→
＊ＳＴＯＲＥＤ＊
