2.6.1.3 Changing the parameter data
1) When the cursor is located at the parameter
number, press
.
2) The cursor moves to the data entry position.
Enter data and press
.
※
※※
※ The cursor does not move if the parameter
is locked.
3) The entered data is stored in Teaching Pendant
and the cursor moves back to the parameter
number.
※
※※
※ Each parameter has the corresponding
setting range. If excessive data is entered,
an error message is displayed.
Even if this happens, the entered value
remains on the screen.
However, with settings such as "parameter
1" where the number has a significant
meaning, the value before entry is restored.
Enter "3."
(Settle)
ＣＡＭ ＣＵＲＶ Ｐ０１
［１］ＭＳ
ＣＡＭ ＣＵＲＶ Ｐ０１
［１］ＭＳ
ＣＡＭ ＣＵＲＶ Ｐ０１
［３］ＭＴ
ＣＡＭ ＣＵＲＶ Ｐ０１
［３］ＭＴ
★
Out of setting range
Enter "101"
(excessive setting).
(Settle)
ＨＭＥＲＴＮ ＳＰＤ Ｐ０５
［ ２．０］ＲＰＭ
ＨＭＥＲＴＮ ＳＰＤ Ｐ０５
［ １０１］ＲＰＭ
ＩＮＰＵＴ ＡＧＡＩＮ
［ １０１］ＲＰＭ
ＨＭＥＲＴＮ ＳＰＤ Ｐ０５
［１０１．０］ＲＰＭ
★
If the number has significant meaning
Enter "6"
(excessive setting).
State waiting for entry
The value before entry
is restored.
ＩＮＰＵＴ ＡＧＡＩＮ
［６］ＭＳ
ＣＡＭ ＣＵＲＶ Ｐ０１
［１］ＭＳ
ＣＡＭ ＣＵＲＶ Ｐ０１
［１］ＭＳ
