CKD AX0180 User Manual

[SMB-66E]
－ 49 －
OPERATION
2
8） Completion of TUNING.
The message on the right is displayed when
TUNING is finished.
After all safety aspects are confirmed (e.g., the
rotation of moving parts will not cause any problems),
press .
If the actuator oscillates, manually adjust the gain.
※If the actuator does not turn servo on, the message
on the right is displayed.
When auto tuning is finished, the TUNING mode
menu is displayed and the cursor moves to “3
TEST”.
※Refer to Section 2.9.3 “TEST Procedure”.
When an alarm is present, data of an alarm
currently in presence is displayed.
※Refer to Section 5.1 “Alarm Display and Description”.
If there are multiple alarms, press
or to display other alarms.
Press
to reset the alarm.
Remove the cause of the alarm and redo “1
TUNING”.
※To return to the menu without resetting the alarm,
press
MODE
while the alarm data is displayed.
ＡＵＴＯ ＴＵＮＩＮＧ ＩＳ
ＦＩＮＩＳＨＥＤ
Alarm number
Description of alarm
ＡＬＡＲＭ Ｕ
ＴＵＮＩＮＧ ＥＲＲＯＲ
★If there are alarms 4 and U
ＡＬＡＲＭ ４
ＡＣＴＵ ＯＶＥＲＬＯＤＯ
ＡＬＡＲＭ Ｕ
ＴＵＮＩＮＧ ＥＲＲＯＲ
＊ＲＥＳＥＴ＊
ＴＵＮＩＮＧ ＭＯＤＥ
←２ＧＡＩＮ ３ＴＥＳＴ
ＣＯＵＬＤ ＮＯＴ ＴＵＲＮ
ＳＥＲＶＯ ＯＮ
