CKD AX0180 User Manual

[SMB-66E]
－ 77 －
COMMUNICATION
FUNCTIONS
6
Code Description Input Data Type Output Data Type
L14 Not to be used
L15 Not to be used
L16
Designation of Program
Number
L16_[Program Number]
Example:
L16_100
0←
L17 Delete of Program Number
L17_[Program Number]
Setting program number to 9999
will delete all programs.
Program number 12345 will
initialize the system.
0←
L18
Change of Program
Number
L18_[Current Program Number]
_[New program number]
Example:
L18_100_200
o100 changed to o200.
0←
L19
Output of the Next Block of
Program to be Executed
L19
[NC Program]←
L20 Not to be used
L21 Mode Output
L21
[Mode]←
Example:
M1←
L22
to L88
Not to be used
L89
Serial actuator number
output
L89
[Serial number]←
Example:
Ser.1234567←
