Clack WS1 Series User Manual

WS1”, 1.5” & 2” Series Watersoftener
Installation Operation Maintenance Manual
SIMPWS1 REV3 13/07/11 PAGE 11 OF27
NEXT
NEXT
NEXT
NEXT
NEXT
NEXT
Capacity in Kilograms-Set according to Softener Size in
Technical data if metered, ignore if timeclock
Set Auto if metered, off if timeclock
Set type of regeneration required:-
“NORMAL” – Delayed Regeneration
“on 0” – Immediate Regeneration “NORMAL + on 0” –
Either Delayed or Immediate Regeneration, whichever
occurs first
Set Salt to Off
Programming Finished – Return to time of day
User Programming
To alter settings – Press “↑” and “↓” keys To back up at any stage – Press
“REGEN” To save any changes – Press “SET CLOCK”
Press together and hold for 5 seconds
Set Influent Hardness in ppm if metered, nA if
timeclock

Clack WS1 Series Specifications

General

Series	WS1
Regeneration	Upflow
Certifications	NSF/ANSI 44
Operating Temperature	34 - 120°F (1 - 49°C)
Power Supply	12 VAC
Type	Water Softener
