Connecting the parking brake cord
Connect the cord to parking brake lamp ground in the meter panel.
Note:
•ConnectingtheparkingbrakecordtolampgroundallowsyoutowatchiPod/iPhonevideo/DVDvideo/AVinputwhen
the parking brake is engaged.
•Whentheparkingbrakecordisnotconnected,themonitorwillnotshowanyvideosources.
•If“AUDIOONLY”appearsonthescreenjustafterturningontheACCpowerofthecar,releasetheparkingbrake
whileconrmingsafety,andthenengagetheparkingbrakeagain.
Connecting the accessories
•Connectingtotheexternalamplier
The external amplifiers can be connected to the 6 channel RCA output connections. Ensure that the connectors
are not grounded or shorted to prevent damage to the unit.
•ConnectingtoiPod/iPhonedevice
The iPod/iPhone device can be connected to dedicated iPod/iPhone connection on the main unit. For detailed
information, refer to the instruction sheet or manual for the iPod/iPhone cable.
Note:
•ThisunitmaynotsupportallfunctionsofalliPod/iPhonedevices.
•TheiPod/iPhoneconnectionwillchargeyouriPod/iPhoneunlesstheiPod/iPhonebatteryiscompletelydepleted.If
thespeciedcordofthecellularphoneisconnectedtothephoneinterruptcordofthemainunit,theaudiomuteis
activated when cellular phone in use.
•ConnectingtoSIRIUSSatelliteRadioReceiver
When SIRIUS Satellite Radio Receiver is to be connected, use the dedicated connector. For detailed
information,refer to the instruction manual of the SIRIUS Satellite Radio Receiver.
Parking brake lamp
cord to battery
Electro-tap
Parking brake
signal cord
Parking brake
signal cord
Stopper
Parking brake
signal cord
Parking brake
Parking brake cord
(Grass-green)
Parking brake cord
(Grass-green)
Howtoattachtheelectro-tap
1. Place the Parking brake cord at the stopper, and
fold it back in the direction of the arrow
2. Pass the Parking brake signal cord through, and
fold it back in the direction of the arrow.
