Clarius Scanner HD3 Clarius Charger HD3
revision 9 31
The Clarius Charger HD3 is designed for use in professional healthcare facilities. The device is
not intended to come in contact with the patient during normal use.
For regular maintenance, clean and disinfect the Clarius Charger HD3. For cleaning
instructions, see Cleaning the Clarius Charger HD3 on page 37. For disinfecting instructions,
see Disinfecting the Clarius Charger HD3 on page 40.
The charger supports various USB-dedicated adapters and USB ports; however, these products
may cause the charger to fail or vary in charge time.
Do not use the Clarius Charger HD3 in air ambulances, regular ambulances, or the EMS
environment in general (including patient transportation and home healthcare).
• If the AC power cord is damaged, contact Clarius for a replacement.
• Charging the scanner in a rotary-wing airborne ambulance may cause the charger’s power
supply to interfere with the aircraft's electrical system, causing a malfunction that could
lead to failure of control, instrumentation, and communication systems.
• Connecting the charger to a power supply that is not manufactured by Clarius may have
the incorrect voltage/current, which could damage the charger.
Components
The Clarius Charger HD3 is made of the following components:
• A fully assembled Clarius Charger HD3 (CIDN 50-02-00069).
• A power supply (CIDN 10-21-00006/Globtek GTM46161) with an adapter compatible with
your country's socket and voltage.
• A removable cable (CIDN 10-18-000026).
Technical Specifications
• Input:
• wall power supply: 100-240 VAC, 50-60 Hz, 0.45 A
• Clarius Charger HD3: 5 VDC, 3.2 A
• Output:
• wall power supply: 5 VDC, 3.2 A
• Clarius Charger HD3: 5 VDC, 3.2 A
• Protection Against Electric Shock: Class II / double insulated
• Applied Part: None
