CLARIUS HD3 - Clarius Scanner L20 HD3

Clarius Scanner HD3
revision 9 82
Clarius Scanner L20 HD3
CLARIUS SCANNER L20 HD3: B-MODE
Measurement Tolerance Range
Axial Distance < ± 2% 0 – 4.0 cm
Lateral Distance < ± 2% 0 – 4.0 cm
CLARIUS SCANNER L20 HD3: M-MODE
Measurement Tolerance Range
Distance < ± 2% 0 – 4.0 cm
Time < ± 2% minimum = 0 ms
maximum = variable
1
1. Range depends on the viewing device used and the amount
of spectrum that can fit on the device's screen.
Heart Rate < ± 2% minimum = ≤ 1 beat
maximum = variable
a
CLARIUS SCANNER L20 HD3: PW-MODE
Measurement Tolerance Range
Velocity < ± 2% 0 – 77.0 cm/s
Time < ± 2% minimum = 0 ms
maximum = variable
1
1. Range depends on the viewing device used and the amount
of spectrum that can fit on the device's screen.
Heart Rate < ± 2% minimum = ≤ 1 beat
maximum = variable
a
CLARIUS SCANNER L20 HD3: DOPPLER SENSITIVITY
Sensitivity Depth (cm) Flow (ml/sec)
PW Doppler flow sensitivity at depth 2.0 0.1
CFI Doppler flow sensitivity at depth 2.0 0.1
PDI Doppler flow sensitivity at depth 2.0 0.1
PW Doppler depth sensitivity 1.9 –
CFI Doppler depth sensitivity 1.9 –
PDI Doppler depth sensitivity 2.0 –
