Clarius Scanner HD3 The Clarius Ultrasound Scanner
revision 9 69
Environmental Specifications
SCANNERS C3 HD3, C7 HD3, EC7 HD3, L7 HD3, L15 HD3, L20 HD3, PA HD3, & PAL HD3
Operating Limits
Transient Operating Conditions
1
1. The conditions under which the scanner can operate for at least 20 minutes immediately
after being removed from an environment of 20°C (60°F), by combining the Clarius
Power Fan HD3, B-Mode, and Eco Mode (extends scanner time at reduced frame rate).
Storage & Transportation Limits
Temperature 0°C (32°F) to 40°C (104°F) -20°C (-4°F) to 35°C (95°F) -20°C (-4°F) to 50°C (122°F)
Humidity 15% to 95% RH 15% to 95% RH 0% to 95% RH
Pressure 620 hPa to 1060 hPa n/a n/a
CLARIUS CHARGER HD3
Operating Limits Transient Operating Conditions Storage & Transportation Limits
Temperature 0°C (32°F) to 40°C (104°F) n/a -20°C (-4°F) to 50°C (122°F)
Humidity 15% to 95% RH n/a 0% to 95% RH
Pressure 620 hPa to 1060 hPa n/a n/a
