Clarius Scanner HD3 Clarius Power Fan HD3
revision 9 34
To charge the scanner:
Place the scanner into the Clarius Charger HD3.
To charge the scanner using the Clarius Power Fan HD3:
1. Clean and disinfect the Clarius Power Fan HD3.
For cleaning instructions, see Cleaning the Clarius Power Fan HD3 on page 37. For
disinfecting instructions, see Disinfecting the Clarius Power Fan HD3 on page 39.
2. Attach the Clarius Power Fan HD3 to the scanner.
For instruction on attaching the Clarius Power Fan HD3 to the scanner, see Clarius
Power Fan HD3 on page 32.
3. Connect the Micro USB cable provided with the Clarius Power Fan HD3 to the Clarius
Power Fan HD3.
4. Connect the USB A to a power supply.
5. Insert the AC male plug into a power source.
The scanner will begin charging.
The scanner LED indicates the charge level of the battery in the scanner:
• Red: 0
– 30%
• Orange: 30
– 65%
• Blue: 65 – 95%
• Green: 95%+
You can continue scanning patients while the scanner charges via the Clarius Power Fan HD3.
Use only power supplies recommended by Clarius when plugging into an AC power outlet.
Do not charge the scanner via the Clarius Power Fan HD3 in air ambulances, regular
ambulances, or the EMS environment in general (including patient transportation and home
healthcare).
