Clark CER10 - General Locations

2 – 1
12. GENERAL LOCATIONS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
FX901
1. Overhead guard
2. Head light
3. Mast
4. Lift Chain
5. Lift cylinder
6. Load backrest
7. Fork
8. Load wheel
9. Straddle leg
10. High pressure hose
11. Hydraulic tank
12. Lift lever
13. Tilt lever
14. Reach lever
15. Emergency lever
16. Travel control lever
17. LCD display panel
18. Key switch
19. Steering wheel
20. Brake pedal
21. Caster wheel
22. Drive wheel
