2 – 15
13.2.2 STEERING WHEEL KNOB, 13.2.3 STEERING WHEEL
When operating the steering wheel, hold the steering wheel knob with your left
hand (Standard machine with electric power steering)
13.2.4 LIFT LEVER
When you pull this lever backward, the fork goes up and push forward, the
fork goes down. You can have a proper lifting speed by controlling this lever.
13.2.5 TILT LEVER
When you pull this lever backward, the fork tilts backward and push forward,
the fork tilts forward. You can have a proper tilting speed by controlling this
lever.
13.2.6 REACH LEVER
When you push this lever forward, the mast goes forward and pull backward,
the mast comes backward. You can have a proper reaching speed by
controlling this lever.
13.2.7 TRAVEL CONTROL LEVER
When you push this lever forward, the machine goes forward, pull backward,
the machine goes backward. You can have a proper traveling speed by
controlling this lever. If you release this lever, it returns to neutral position
automatically.
13.2.8 EMERGENCY LEVER (IN EMERGENCY)
If you want to disconnect battery, push this lever. In emergency if you push
this lever, the power is OFF.
13. DRIVING AND OPERATING
In case of the machine installed with power steering, if you pull out this
lever, steering wheel becomes heavy. Ttherefore, pay attention to operate
this lever while traveling.
CAUTIONS
