Clarke
®
Operator's Manual - BOOST 28 Page -29-
Ref. # Part No. Description Qty Qty
1 Ref Assembly, Recovery Tank Ref Ref
2 Ref Assembly, Control Panel Ref Ref
3 30064A Rear Cover 1 -
4 80108A Screw, 10-24 x ½ SS 4 4
5 70080A Plate, Warning 1 1
6 83010A Rivet, Pop
1
/8 2 2
7 Ref Assembly, Rear Panel Ref Ref
8 980651 Washer,
5
/16 Flat 11 11
9 920110 Nut,
5
/16 -18 ESNA 4 4
10 980652 Washer,
5
/16 Lock 7 7
11 85811A Screw,
5
/16 -18 x ¾ 7 7
12 See pg Assembly, Squeegee 32” Ref Ref
13 See pg Assembly, Squeegee Lift Ref Ref
14 See pg Assembly, Traverse System Ref Ref
15 980982 Washer #10 2 2
16 Ref Assembly, Brush Head Ref Ref
17 81105A Nut,
3
/8-16 ESNA 4 4
18 87031A Washer,
3
/8 Flat SS 4 4
19 50965A Hinge 1 1
20 85395A Screw, ¼-20 x
1
/2 SS 6 6
21 30249R Front Cover 1 1
22 50966A Latch, Front Cover Ref Ref
23 930090 Rivet,
5
/32 x
9
/16 2 2
24 Ref Assembly, Solution Tank Ref Ref
25* 40136A Battery 6V, 250 AH (wet - Stud Post) 4 4
40137A Battery 6V, 250 AH (dry - Stud Post) 4 4
891384 Battery, 6V 330 AH (wet - UT Post) 4 4
891385 Battery, 6V 330 AH (dry - UT Post) 4 4
26 41206A Series Battery Cable (Taper Style) 3 3
41217A Series Battery Cable (Ring Style) 3 3
27 980205 Washer,
5
/16 Fender 4 4
28 85734A Screw,
5
/16-18 x 2 2 2
29 85739A Screw,
5
/16-18 x 3 Hex 2 2
30 87026A Washer, ¼ flat SS 5 5
31 41211A Battery, Cable (Taper Style) 1 1
40174A Battery, Cable (Ring Style) 1 1
32 85518A Screw, ¼-20 x
3
/4 5 6
33 85391A Screw, ¼-20 x
5
/8 - 2
34 61780A Bracket, Cord Wrap - 1
35 87007A Washer, ¼ Flat - 2
36 81217A Nut, ¼-20 - 2
37 53851A Bushing - 1
38 40740A Cord, Power - 1
39 30640A Rear Cover - 1
NI 40512A Battery charger 1 -
NI 77092A Label, Gases 1 1
NI 77093A Label, Falling 1 1
NI 70226A Label, Battery 1 1
NI 10072A Parking Brake Assembly 1 1
* See page 12 for installation.
Clarke
®
Final Assembly Parts List 9/05
Remote
Charger
On-Board
Charger
To Next Page
