Operator's Manual - BOOST 28 Page -43-
Ref. # Part No. Description Qty
1 80252A Screw, ¼-20 x 1 Hex SS 4
80253A Screw, ¼-20 x 1½ Hex SS 4
2 980657 Washer, ¼ Lock 4
3 60243A Bracket, Squeegee Wheel 2
4 30049B Wheel, Squeegee 4
5 81104A Nut, ¼-20 2
6 60254A Bolt, Shoulder
5
/16x 2¼ 2
7 50958A Ring,
3
/8 ID Snap 2
8 30048A Wheel, Guide, 4 Inch Diameter 2
9 60272A Channel, Squeegee Weldment 39” 1
10 50835A Latch, Squeegee Clamp 1
11 930086 Rivet, 3/16 x .450 Aluminum 2
12 60252A Strap, Clamp, Squeegee Retainer 39” 1
13 30069A Blade, Rear, Gum Rubber, 39” 1
14 30058A Spacer, Squeegee 39” 1
15 30091A Blade, Front Ribbed 39” 1
16 80011A Screw,
3
/8-16 x 3 2
17 81301A Nut,
3
/8-16 Jam SS 2
18 34260B Gasket 1
19 25201A Knob 2
20 60358A Shim, Squeegee Wheel 2
21 61370A Weight 8
22 80280A Nut, Squeegee Backup 2
Clarke
®
Squeegee Assembly Parts List 9/05

Clarke BOOST 28 Specifications

General

Solution Tank Capacity	28 gal (106 L)
Recovery Tank Capacity	30 gal (114 L)
Cleaning Path	28 inches
Brush Motor	1.5 HP
Power Source	Battery
Weight	490 lb (w/o batteries)
Tank Capacity	28 gallons
