Operator's Manual - BOOST 28 Page -31-
Ref. # Part No. Description Qty
1 962798 Screw, 10-24 x .5 1
2 30057A Lid 1
3 81110A Nut, 10-24 SS 1
4 30065A Gasket, Lid 1
5 58069A Strainer 1
6 39338A Stand Tube 1
7 837304 O-Ring 2
8 10660A Switch Kit, (Includes 8A, 8B, 9) 1
8A 40002A Switch (included in Item 8) 1
8B 56459A Relief, Strain (included in Item 8A) 1
9 59877A Seal, Washer 1
10 30248A Tank, Recovery 1
11 60373A Latch, Recovery Tank 1
12 87622A Washer, Nylon 5/16 x 5/8 x 1/32 1
13 80043A Screw, .25 x 20 x .25, Shoulder 1
14 60336A Strap, Hose Retainer 1
15 85100A Screw, 10-32 x ½ SS Xylan Coating 2
16 30068A Hinge, Pin (included w/ item 10) 2
17 43402A Housing, Connector(included in 8A) 2
18 41809A Contact (included in 8A) 4
19 82100A Nut, Strain Relief Lock 1
20 872010 Clamp, Hose 1
21 35165A Hose, Drain 1
22 832002 Clamp, Hose 1
23 839401 Valve, Drain 1
24 962943 Screw, 8-18 x ½ PN 1
25 52206A Chain 1
26 962987 Screw, 10-24 x 3/8 Pan 1
27 833901 Drain, Valve Handle 1
28 833407 Gasket, Drain Valve 1
29 51060A Hose, Squeegee 1
30 830208 Squeegee Stand Tube 1
31 80110A Hose Clamp 1
32 752020 Hose Clamp 1
33 43401A Housing, Vac Motor Connector 2
34 674110 Hose 1
35 85728A Screw, ¼-20 x 4 Hex 3
36 87026A Washer, ¼ Flat 3
37 51049A Motor, Vacuum (3-Stage) 1
51050A Motor, Vacuum, (2-Stage Option) 1
38 643418 Gasket 1
39 58533A Spacer 3
40 920797 Nut 1
41 962666 Screw, 10-24 x ¾ 1
42 920296 Nut, 10-24 Elastic 1
43 38020A Strap 1
NI 839410 Valve Asm. (includes 23, 24, 25, 26, 27, 28) 1
NI 70226A Label, Battery Installation 1
Clarke
®
Recovery Tank Assembly Parts List 9/05

Clarke BOOST 28 Specifications

General

Solution Tank Capacity	28 gal (106 L)
Recovery Tank Capacity	30 gal (114 L)
Cleaning Path	28 inches
Brush Motor	1.5 HP
Power Source	Battery
Weight	490 lb (w/o batteries)
Tank Capacity	28 gallons
