Clarke BOOST 28 User Manual

Clarke
®
Operator's Manual - BOOST 28 Page -35-
Ref. # Part No. Description Qty
1 920224 Nut, 10-32 2
2 980603 Washer, Starlock 4
3 920056 Nut, 6-32 5
4 46106A Rectifier 1
5 40863A Harness, Power “L” 1
6 962212 Screw, 6-32 x 7/8 3
7 85383A Screw, 10-32 x ¾ 1
8 41810A Solenoid, Brush 1
9 85395A Screw, ¼-20 x ½ 6
10 980614 Washer, Starlock, ¼ 10
11 85391A Screw, ¼-20 x 5/8 4
12 60261A Panel, Rear Metal 1
13 60257A Cable, Squeegee Lift 1
14 920346 Nut, Pal 1
15 80028A Bolt, Shoulder, 5/16 x 1.0 1
16 980692 Washer, Flat 5/16 SS 2
17 438360 Spring 1
18 64901A Lever, Squeegee Lift 1
19 64490A Handle, Squeegee 1
20 980666 Washer, 3/8 Starlock 1
21 85389A Screw, 3/8-16 x 5/8 1
22 68643A Plate, Vacuum Wear 1
23 962968 Screw, 10-24 x ½ 2
24 61260A Plate, Squeegee Lift 1
25 47388A Switch, Vacuum Lever 1
26 85601A Screw, 6-32 x 1¼ PN 2
27 81217A Nut, ¼-20 x .218H Nylock 1
28 60264A Bracket, Power Connector 1
29 41146A Cable, Assembly Console 1
30 193951 Grommet, slotted, 8” Ref
31 41811A Solenoid, Main 1
32 40157A Harness, Traverse 1
33 40169A Solenoid, Vacuum 1
34 962798 Screw, 10-24 x ½ 2
35 40132A Control, Traverse 1
36 30097A Insulator, Mylar 1
NI 77093A Label, Falling Parts 1
NI 77092A Label, Gases 1
.
Clarke
®
Rear Panel Assembly Parts List 9/05
Remote Charger

Clarke BOOST 28 Specifications

General

Solution Tank Capacity	28 gal (106 L)
Recovery Tank Capacity	30 gal (114 L)
Cleaning Path	28 inches
Brush Motor	1.5 HP
Power Source	Battery
Weight	490 lb (w/o batteries)
Tank Capacity	28 gallons
