Operator's Manual - BOOST 28 Page -39-
Clarke
®
Control Panel Assembly Parts List 9/05
Ref. # Part No. Description Qty
1 55413A Key (included w/Item 3) Ref
2 84237A Screw, 10-32 x ½ 2
3 47380A Switch, Key 1
4 60334A Panel, Key Switch 1
5 80108A Screw, 10-24 x ½ SS Black Xylan 8
6 87052A Washer, Switch 1
7 962262 Screw, Set 8-32 x ½ (included in item 29) 4
8 50962A Traverse, Control Knob 1
9 85703A Screw, 10-00 x ½ PN 1
10 962957 Screw, 10-16 2
11 40135A Harness, Potentiometer Assembly. 1
12 60259A Bracket, Traverse Switch 1
13 980666 Washer, 3/8 Starlock 1
14 40158A Switch, Reverse 1
15 980603 Washer 4
16 920224 Nut, 10-32 Hex 4
17 30072A Control Handle -
18 85391A Screw, ¼-20 x
1
/2 SS Ref
19 87026A Washer, ¼ SS Ref
20 40858A Control, Solution 1
21 41422A Breaker, Circuit 25 Amp Traverse 1
23 41448A Breaker, Circuit 30 Amp Vac/Brush 2
24 41423A Breaker, Circuit 5 Amp Actuator 1
25 71078A Label, control 1
26 61812A Panel, Control, Metal 1
27 40217B Meter, Battery 1
28 47381B Switch, Brush Adjustment 1
29 55502A Knob 1
30 30096A Gasket, Switch 1
31 962330 Screw, 6-32 x
3
/8 4
32 980608 Washer 4
33 30056A Housing, Switch & Lever 2
34 30055A Lever, Switch 2
35 50961A Spring, Switch 4
36 40126A Switch, Forward/Reverse 2
37 80104A Screw, 10-32 x ½ SS Black Xylan 4
38 70219A Label, Key Switch 1
39 34264A Gasket, Panel 1
NI 47708A ¼ F.I.M.Q.D. 4
NI 47712A ¼ F.I.F.Q.D. 1

Clarke BOOST 28 Specifications

General

Solution Tank Capacity	28 gal (106 L)
Recovery Tank Capacity	30 gal (114 L)
Cleaning Path	28 inches
Brush Motor	1.5 HP
Power Source	Battery
Weight	490 lb (w/o batteries)
Tank Capacity	28 gallons
