Clarke BOOST 28 User Manual

Ref. # Part No. Description Qty
1 85700A Screw, ¼-20 x 1 1
2 85811A Screw,
5
/16-18 x ¾ 6
3 980652 Washer,
5
/16 Lock 6
4 980651 Washer, flat
5
/16 6
5 60328A Squeegee Mount Ref
6 60260B Frame Assembly 1
7 50968A Caster, Assembly 1
8 61437A Wheel Assembly 2
9 50967A Transaxle w/mounting hubs 1
10 60289A Mount, Transaxle 2
11 87031A Washer, flat
3
/8 SS 4
12 170883 Washer,
3
/8 Lock 4
13 80103A Screw,
3
/8-24 x 1 Hex SS 4
14 57423A Ring, Snap Retainer 2
15 87616A Washer, Nylon 2
16 980205 Washer,
5
/16 Fender 2
17 962620 Screw,
5
/16-24 x ¾ 2
18 87026A Washer, Flat, ¼ SS 8
19 81104A Nut, ¼-20 ESNA SS 9
21 77267A Label, Tie Down 4
22 980614 Washer, ¼ Starlock 5
23 81108A Nut,
3
/8-24 ESNA 4
24 81105A Nut,
3
/8-16 ESNA Ref
25 87031A Washer, Flat
3
/8 SS Ref
26 Ref Solution Tank Ref
27 980205 Washer,
5
/16 Ref
28 85734A Screw,
3
/8-16 x 2 Ref
29 69639A Strap, Static 1
30 10135A Flange, Hub Kit 1
*NOTE: 10135A (Flange, Hub Kit) contains 1 flange (hub), 2 snap rings, and 2
retaining keys.
Clarke
®
Frame Axle Assembly Parts List 9/05
Clarke
®
Operator's Manual - BOOST 28 Page -45-

Clarke BOOST 28 Specifications

General

Solution Tank Capacity	28 gal (106 L)
Recovery Tank Capacity	30 gal (114 L)
Cleaning Path	28 inches
Brush Motor	1.5 HP
Power Source	Battery
Weight	490 lb (w/o batteries)
Tank Capacity	28 gallons
