Clarke BOOST 28 User Manual

Ref. # Part No. Description Qty
1 766780 Pin, Hair 5
2 782002 Clamp, Manifold 3
3 915082 Key, 3/16 SQ. x 3/4” 1
4 920278 Nut, Jam ½-20 4
5 925589 Pin, Roll 1
6 962098 Screw, ¼-20 x 3/4” 1
7 980022 Washer, Wave 2
8 980614 Washer, ¼” Starlock, External 8
9 980626 Washer, ½ Lock 2
10 980646 Washer, ¼” flat 2
11 980657 Washer, Lock ¼ 1
12 11003A Tube Assembly, Drip 28” 1
13 30048A Wheel, Guide 2
14 30206A Bumper 1
15 30663A Plate, Driver 1
16 30670A Spacer, Nylon 2
17 30671A Spacer, Nylon 2
18 30674A Plate, Flex, Asm. 32” 2
19 38723A Spacer, 1.00 x .632 x .185 2
20 40790A Motor, 24V 1
NI 11055A Kit, Motor Brush Replacement 1
21 50736A Bearing 1
22 53847A Actuator 1
23 11063A Rubber Isolator Kit 1
24 59789A Valve, Solution 1
25 61425A Retainer, Bumper 1
26 61724A Retainer, Eccentric 1
27 61729A Plate, Upper 28 1
28 61731A Arm, Lift, Left 1
29 61732A Arm, Lift, Right 1
30 61733A Bracker, Lift 2
31 61750A Rod Lift 1
32 61753A Eccentric 1
33 61775A Retainer, Bearing 1
34 61782A Sleeve, Guide Wheel 2
35 80296A Screw #10-24 x 7/16 Type 23 5
36 80298A Screw, ¼-20 x 2.00 Hex Cap 2
37 81217A Nut, ¼” x .218 ESNA 9
38 81220A Nut, Serrated Flange 12
39 82501A Pin, Clevis 1
40 84236A Screw, 10-32 x .50 FH 4
41 84237A Screw, 10-32 x .50 P.H. 3
42 85301A Screw, ¼-20 x 1-¼ C.R.P.H. 2
43 85395A Screw, ¼-20 x ½” P.H. 5
44 85737A Screw, ¼-20 x ½ H.H.C.S. 1
45 85838A Screw, ½-20 Hex 2
46 87607A Washer, Flat 4
47 61813A Guard, Front 1
48 962139 Screw, 1/4-20 x .625 Hex Cap 4
49 997004 Pad, Red, 32” 1
50 30708A Endcap 2
51 722030 Clamp, Hose 4
52 30707A Hose 1
53 40645A Housing 2
54 41601A Connectors 2
55 60236B Bracket, Brush Head 1
56 11062A Rubber Mounting Kit 1
Clarke
®
Brush Head Assembly Parts List 9/05
Clarke
®
Operator's Manual - BOOST 28 Page -47-

Clarke BOOST 28 Specifications

General

Solution Tank Capacity	28 gal (106 L)
Recovery Tank Capacity	30 gal (114 L)
Cleaning Path	28 inches
Brush Motor	1.5 HP
Power Source	Battery
Weight	490 lb (w/o batteries)
Tank Capacity	28 gallons
