Clarke BOOST 28 User Manual

Clarke
®
Operator's Manual - BOOST 28 Page -33-
Ref. # Part No. Description Qty
1 872010 Clamp, Hose 1
2 50964A Hose, Drain 1
3 30244A Tank, Solution 1
4 59614A Valve, Battery Drain 1
5 Hose Clamp
6 30453A Hose, Clear Vinyl 1
7 820207 Adapter, Hose 3/8 MPT x ½ Hosebarb 1
8 53562A Filter, Bowl Asm 1
11 30446A Hose 1
12 51204A Valve, 3/8 NPT Shut Off Pg. 46
13 59789A Valve, Electric 1
15 81109A Nut, 8-32 ESNA SS 1
16 50966A Latch 1
17 80105A Screw, 8-32 x 1¼ SS 2
18 50963B Screen, Fill (with hose retention) 1
51308B Strainer (without hose retention) 1
19 69879A Bracket, Latch 1
20 170892 Washer, Lock ¼ 2
21 170915 Screw, ¼-20 x ¾ SS Hex 2
23 60480A Bracket, Hose 1
24 51346A Spring, Hose 1
25 80108A Screw, 10-24 x ½ 2
NI 30162A Funnel (included w/Kit 10177A) 1
NI 10177A Kit, Solution Fill 1
(includes #18-51308A)(includes NI - 30162A)
53562A Components
Clarke P/N Description Qty.
50081A Bowl, Filter 1
53563A Filter, Screen 1
53564A Upper Body 1
54369A Gasket, Bowl 1
Clarke
®
Solution Tank Assembly Parts List 9/05

Clarke BOOST 28 Specifications

General

Solution Tank Capacity	28 gal (106 L)
Recovery Tank Capacity	30 gal (114 L)
Cleaning Path	28 inches
Brush Motor	1.5 HP
Power Source	Battery
Weight	490 lb (w/o batteries)
Tank Capacity	28 gallons
