Clarke BOOST 28 User Manual

Ref. # Part No. Description Qty
1 61263A Bracket Tube 1
2 85730A Screw, 3/8-16 x 1¼, Hex SS 1
3 980638 Lockwasher, 3/8 LT Spring Type 1
4 69860B Bracket, Pin 1
5 87026A Washer, ¼ SS 2
6 170915 Screw, ¼-20 x ¾ 4
7 962481 Screw, ¼-20 x 1¼ Hex 2
8 87031A Washer, 3/8 Flat 3
9 920208 Nut, ¼-20 2
10 81111A Nut, 3/8-16 ESNA 1
11 80101A Screw, ¼-20 x 3¼ SS 1
12 85811A Screw, 5/16-18 x ¾ 1
13 67867A Nut, spacer 1
14 60256A Squeegee, Pivot Arm 1
15 81104A Nut, ¼ Nylock 5
16 60255A Bracket, Squeegee 1
17 60328A Mount, Squeegee 1
18 81112A Nut, 5/16-18 Thin ESNA SS 1
19 Page 35 Cable, Squeegee Lift Ref
20 Page 35 Lift Handle Assembly Ref
21 920346 Palnut Ref
22 980651 Washer 1
Clarke
®
Squeegee Lift Assembly Parts List 9/05
Clarke
®
Operator's Manual - BOOST 28 Page -41-

Clarke BOOST 28 Specifications

General

Solution Tank Capacity	28 gal (106 L)
Recovery Tank Capacity	30 gal (114 L)
Cleaning Path	28 inches
Brush Motor	1.5 HP
Power Source	Battery
Weight	490 lb (w/o batteries)
Tank Capacity	28 gallons
