Clarke
®
Operator's Manual - BOOST 28 Page -7-
10. Fasten the machine to the vehicle. Clarke
recommends a strap over the top of the
machine and a strap to keep the machine from
rolling forward or backwards. If this is not
done, there is a possibility of the machine
toppling over. Four tie down points (2 along
each side of frame) are provided on machine for
securing machine.
How to Remove the Machine From a Van or
Truck
1. Make sure there are no obstructions in the area.
2. Make sure the unloading ramp is at least eight
(8) feet (2.5m) long and a minimum of 32"
(0.8m) wide, and strong enough to support the
machine.
3. Make sure the ramp is clean and dry.
4. Put the ramp in position.
5. Unfasten the machine.
WARNING: The machine is heavy.
Make sure you use two able
persons to assist in moving
the machine down the
ramp.
6. Turn the key switch "ON".
7. Set the traverse center knob to the slowest
forward speed setting. Carefully and slowly,
drive the machine to the top of the ramp and
start down.
8. While pushing in the right or left forward/reverse
switch the machine will go forward. See figure
2.
9. As the machine begins to travel down the ramp,
push in the forward/reverse switch to maintain a
slow downward speed.
10. Replace squeegee assembly after machine is
unloaded and ready to use.
Procedures For Transpoting (cont.)
Figure #2
